High Brightness, Long Life, Stable Performance
The Product Range Covers the Full LED Spectrum

Video Display Product

Digital Signage Product

Stage Lighting Product

Flip Chip Product

Plant Lamp Products

Infrared Product

Chip Series		Applicable Package	Application	Performance Parameters	Advantages
R1 Series 620-625nm	05R	2121	>P2.5	80-110mcd	High Brightness, High Temperate aging, 100% Binning
	06R	2121/1515	P2.0-P2.5	80-130mcd
	8CR、8AR	1010/0808	P1.2-P2.0	100-155mcd, 170-220mcd
	07RS	1921/2727/3535	P3-P8	200-330mcd
	08RS			240-360mcd
	09RS			360-420mcd
	10RS		P3-P12	420-600mcd
	12RS	2727/3535		420-600mcd
	14RS			460-660mcd
	12TS	346	P8-P14	460-660mcd

Expand to see more product parameters

Chip Series		Applicable Package	Application	Performance Parameters	Advantages
G1 Series 568-572nm	7AG1,7BG1 ,07G1	0603, 0402, 0805, 346 Chip Level Package, Through-hole Lamp Package, 7-segment Display	Matrix Display	32-70mcd, 35-80mcd, 45-95mcd	High Consistency and Flexible Application
	08G1			45-95mcd
G3 Series 566-570nm	07G3			14-50mcd
Y1 Series 586-591nm	7AY1,7BY1 ,07Y1			45-80mcd, 65-125mcd
	08Y1			45-80mcd, 55-175mcd
	9AY1			110-175mcd
	10Y1			330-460mcd
Y3 Series 583-588nm	07Y3	0603, 0402, 0805, 346 Chip Level Package, Through-hole Lamp Package, 7-segment Display	Matrix Display	8-22mcd	High Consistency and Flexible Application
O1 Series 600-606nm	7AO1、7BO1			80-140mcd
	08O1			75-170mcd
	9AO1			70-130mcd/td>
O3 Series 598-603nm	07O3			8-22mcd
R1 Series 620-625nm	7AR1,7BR1 ,07R1	0603, 0402, 0805, 346 Chip Level Package, Through-hole Lamp Package, 7-segment Display	Matrix Display	35-80mcd, 65-115mcd, 110-165mcd	High Consistency and Flexible Application
	08R1			35-80mcd
	9CR1			130-165mcd
R4 Series 630-636nm	7BR4/07R4			19-50mcd
	08R4			24-60mcd,160-240mcd
R5 Series 638-643nm	07R5			14-32mcd
	08R5			14-32mcd
Ultra-thin Digital Signage Series(chip thickness 100um)	07G1	0603, 0402, 0805, 346 Chip Level Package, Through-hole Lamp Package, 7-segment Display	Matrix Display	35-80mcd	High Consistency and Flexible Application
	08G1			35-80mcd
	08G1			35-80mcd
	08Y1			75-150mcd
	08O1			75-135mcd
	08R4			28-60mcd
	08R1			45-95mcd, 115-185mcd、240-360mcd
AlGaAs Series	07G3566-570nm	14-50mcd		14-50mcd
	07Y3583-588nm			8-22mcd
	07O3598-603nm			8-22mcd

Expand to see more product parameters

Chip Series		Applicable Package	Application	Performance Parameters	Advantages
R1 Series 620-625nm	16mil	5050/Ceramic/EMC/K1	Stage Lighting	3600-4800mcd	100% Test and Binning, Brightness is High, Long Service Life
	20mil			3200-4400mcd
	26mil			9000-14000mcd
	30mil			9000-16000mcd
	38mil			9000-16000mcd
	42mil			7500-14000mcd

Expand to see more product parameters

Chip Series		Applicable Package	Application	Performance Parameters	Advantages
11 Series 620-625nm		FC on PCB	General Lighting, Display	40-70mcd	100% Test and Binning, Brightness is High, Long Service Life, and Flip-chip Design

Expand to see more product parameters

Chip Series	Measurement	Applicable Package	Application	Performance Parameters	Advantages
R6 Series 650-670nm	10mil	2835/5050/K1/Ceramic/EMC	Horticulture Lighting	7-12mW	100% Test and Binning, Brightness is High, Long Service Life
	14mil			9-15mW
	20mil			80-110mW
	42mil			175-250mW
	45mil			225-325mW
R7 Test 680-700nm	20mil	2835/5050/K1/Ceramic/EMC	Horticulture Lighting	65-95mW
R8 Series 720-740nm	20mil			65-95mW
	42mil			175-250mW

Expand to see more product parameters

Chip Series	Measurement	Applicable Package	Application	Performance Parameters	Advantages
850 Series	10mil Reversed Polarity	SMD 2835	Security Surveillance, Touch Panel	15-23mW@50mA	100% Test and Binning, Brightness is High, Long Service Life
	14mil Reversed Polarity			33-43mW@100mA
	20mil Reversed Polarity	EMC3030, Ceramic 3535, K1		80-160mW@250mA
	28mil Reversed Polarity			180-200mW@350A
	35mil Reversed Polarity			160-240mW@350A
	42mil Reversed Polarity			200-280mW@350A
940 Series	7mil Positive Polarity	Through-hole	Security Surveillance, Touch Panel	1.04-1.58mW@5mA
	9mil Positive Polarity			12-15mW@50mA
	10mil Positive Polarity			18-23mW@50mA
	12mil Positive Polarity			18-33mW@100mA
	14mil Positive Polarity			18-33mW@100mA
	10mil Reversed Polarity	SMD 2835	Security Surveillance, Touch Panel	12-18mW@50mA
	14mil Reversed Polarity			33-43mW@100mA
	24mil Reversed Polarity			130-160mW@350mA
	42mil Reversed Polarity	K1/Ceramic/EMC		180-220mW@350mA

Expand to see more product parameters
